Vibration & Reliability Calculators

Practical calculations for learning, measurement planning and maintenance analysis. Choose a tool, enter your values and calculate.

TOOL 10

ISO 20816-3 guided check

Select your equipment and measurement conditions for a preliminary broadband velocity-zone assessment. This tool implements a limited bearing-housing check, not the complete standard.

Enter values above, then select Calculate.

Group selection must be verified: Group 1 uses power above 300 kW, or electrical-machine shaft height at least 315 mm; Group 2 uses power above 15 through 300 kW, or electrical-machine height 160 to less than 315 mm. Conflicting classifications need review. Support is a dynamic property in each direction, not simply concrete versus steel. Use all required bearing locations; this result assesses only the entered reading. This implementation withholds velocity-only zones at 600 RPM or below. Between 600 and 1000 RPM it conservatively requires the 2 Hz band. Zone boundaries are not automatic alarm or trip setpoints.

View severity tables

These are the velocity boundaries used by this calculator. Values are in mm/s RMS, measured on non-rotating bearing housings or pedestals. Select the correct group and support before comparing a reading.

Velocity zone boundaries — Groups 1 and 2
Machine groupSupportA/BB/CC/D
Group 1Rigid2.34.57.1
Group 1Flexible3.57.111.0
Group 2Rigid1.42.84.5
Group 2Flexible2.34.57.1
How this tool displays the zones
ZoneReadingPractical interpretation
ABelow A/BLow overall magnitude; faults may still be present.
BAt A/B, below B/CUsually compatible with long-term operation; review trends.
CAt B/C, below C/DInvestigate promptly and plan corrective work.
DAt or above C/DUrgent engineering review; follow approved site procedures.

Example: Group 2 with rigid support, 3.7 mm/s RMS, falls in Zone C. Equality is assigned to the higher zone by this tool. These zones are not automatic alarm or shutdown settings.

Reference cross-check: Mobius Institute, Category II course manual (2016), Chapter 18, printed page 18-7, Figure 18-7, presents matching Group 1 and 2 velocity boundaries under the older ISO 10816-3 designation. This is an original RCM GLOBAL summary, not a scan of the manual. Older pump groups are not included. Displacement and shaft-vibration tables are not implemented here.

Basis: ISO 20816-3:2022, preliminary non-rotating-part velocity check. Verify measurement procedure and machine applicability against the full standard. No ISO endorsement or certification. ISO scope and edition status · Adash instrument guide: velocity boundaries. Reviewed 20 October 2026. Numerical limits do not diagnose bearing or gear defects; review trends and manufacturer limits separately.

TOOL 01

RPM ↔ Hz

Convert rotational speed to shaft frequency.

Enter values above, then select Calculate.

Hz = RPM ÷ 60. Shaft frequency is not necessarily the dominant vibration frequency.

TOOL 02

Vibration amplitude

Convert displacement, velocity and acceleration at one frequency.

Enter values above, then select Calculate.

Single sinusoid only: v = 2πfx; a = (2πf)²x. Peak = √2 × RMS; peak-to-peak = 2 × peak. Do not convert broadband overall values using one frequency. Standard gravity: 1 g = 9.80665 m/s². All results below use RMS.

TOOL 03

Gear mesh frequency

Calculate mesh frequency from one gear’s speed and tooth count.

Enter values above, then select Calculate.

GMF = teeth × RPM ÷ 60. Use the speed and tooth count of the same gear. Mesh harmonics alone do not establish a fault.

TOOL 04

Bearing frequencies

Estimate theoretical frequencies from bearing geometry.

Enter values above, then select Calculate.

Stationary outer ring, rotating inner ring, ideal rolling without slip. Use the manufacturer's internal geometry, not bore or outside diameter. Frequencies are diagnostic reference values, not proof of damage. BSF is spin frequency; a rolling-element defect may excite 2 × BSF.

TOOL 05

MTBF, MTTR & availability

Summarise a repairable asset’s completed failure-and-repair history.

Enter values above, then select Calculate.

MTBF = operating hours ÷ failures; MTTR = active repair hours ÷ completed repairs. Use the same observation period and only completed failure-repair events. Inherent availability = MTBF ÷ (MTBF + MTTR). It excludes planned maintenance, logistics and administrative delays; it is not operational availability or a remaining-life prediction. With zero failures, MTBF and MTTR cannot be estimated by these ratios.

TOOL 06

FFT measurement planner

Connect sample rate, record length, frequency spacing and shaft revolutions.

Enter values above, then select Calculate.

Record duration T = N/fs; bin spacing Δf = fs/N; revolutions = RPM × T/60. Nyquist frequency fs/2 is a mathematical boundary, not the usable bandwidth of an instrument. Set Fmax strictly below it and check the instrument's anti-alias filter. Bin spacing is not guaranteed peak separation: window choice and noise matter. No zero padding assumed.

TOOL 07

Blade & vane passing

Find passing frequency, harmonics and first shaft-speed sidebands.

Enter values above, then select Calculate.

Passing frequency = blade count × RPM/60. Sideband markers = passing frequency ± shaft frequency. These are theoretical markers, not predicted amplitudes or a fault diagnosis.

TOOL 08

Your alarm-limit comparison

Compare one reading with limits approved for your asset.

Enter values above, then select Calculate.

Enter your own limits from the equipment maker or your approved monitoring programme. No ISO limits are supplied. Reading and limits must share bandwidth, location, operating condition and RMS convention. At equality the higher category applies. A reading below warning does not prove the machine is healthy.

TOOL 09

Waveform & phase simulator

Explore two equal-frequency sine waves and their sum.

Enter values above, then select Calculate.

Blue: A · orange: B · green: sum. Horizontal axis: time (seconds); vertical axis: amplitude (arbitrary units).

A(t) = A sin(2πft); B(t) = B sin(2πft + φ). The plot spans two cycles. Resultant peak = √(A² + B² + 2AB cos φ); RMS = peak/√2. Educational signals only, not measured machine data.

Measurement references: NI: FFTs and windowing; SKF: introduction to vibration monitoring.

Formulas and references

Bearing formulas: r = (d/D) cos θ; shaft frequency f = RPM/60; BPFO = Zf(1−r)/2; BPFI = Zf(1+r)/2; FTF = f(1−r)/2; BSF = Df(1−r²)/(2d).

Reference reading: SKF: bearing vibration frequencies; IBM: MTTR and MTBF; IBM: availability formula.

Check units, measurement conventions and equipment data before using a result in an engineering decision. No values are uploaded by these calculators.
